Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 311
)lane of projection. Thus in a circular building aseries of similar windows are in elevation at different angles, conse-(juently the widths differ, V)ut the heights ilo not. … II, M Pig. 10. Baluster.; 246 ARCHITECTURAL DRAWING It is necessary to become familiar with these conditions of draw-ing which occur frequently. It is here above all that geometry willbe very useful, for that study includes the planes of projection andplanes of development. While there is some…
Architecture · Building · Carpentry
