chen through aregister set near the kitchen ceiling. The kitchen sink (j) shouldalways be shown with drip-board. A kitchen or ])antry dresser (k)should be shown with doors opening out—not sliding, unU3ss thespace is very limited. Laundry tubs (I) should be shown as indi-cated in the drawing. A… … Jbig. 28. 66 ARCHlTECTlllAI. DRAWING Basement Plan. Fig. 28 shows the basement plan of the resi-dence. Dmiensions are all given to the outside of the underpinningrubble wall, which in this case is 2 inches outside the sill line, as shownin tlie half-inch scale section. ^Tlie footings of piazza…
