Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 253
n boiler ^ 12000 X 0.60 X 6.7 capacities in the chapter on Heating Boilers, it will be seen that an 5-25-7 Ideal cast-ironboiler having a grate area of 8.16 sq. ft. is required. The depth of fire -pot of this boiler should also be checked as indicated under the chapter on Heating Boilers, in order… … Fig. 60. 240 HEATING AND VENTILATION in the chapter on Chimneys for Heating Boilers, for a stack of the height shown in the eleva-tion section, and a flue Uning selected from table of flue Unings. The height of chinmey ismeasured from the grate level to top of masonry which should be at least 2-0…
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
