Fig. 120. Intersectioa ofPlane and Pyramid Fig. 121. Intersection of Planeand Prism … Fig. 122. Intersectionof Plane and Cone Fig. 123. Intersection of Plane and Square Pyramid Fig. 124. Intersection of Plane and Hexagonal Pyramid 95 7G MECHANICAL DRAWING hut inclined at an angle to the horizontal plane of projection; andlet all the sides of the base be at an angle with the ground…
