ion withB S is the point sought. Planes with Cones or Cylinders. Sec-tions cut by a plane from a cone havealready been defined as conic sections.These sections may be any of the follow-ing: two straight lines, circle, ellipse,parabola, hyperbola. All except the pa-rabola and hyperbola may also be… … Fia:. 126. Frustum ofPentagonal Pyramid 97 78 MECHANICAL DRAWING Ellipse. In Fig. 127 the plane cuts the cone obliquely. Tofind points on the c^urve in plan take a series of horizontal planes.r y z, etc., between points c^ and cP. One of these planes, as iv,should be taken through the center of c…
