Fig. 163. Isometric of a Hollow Cylinder Fig. 164. Isometric of aWooden Model any distance which hi plan is parallel to a side of the circumscribingrectangle, is shown in isometric in its true length and parallel to thecorresponding side of the isometric rectangle. If point 3 were on thehorizontal…
