Fig. 167. Oblique View ofCube at 60° Fig. 168. Oblique View of Hollow Cylinder Figs. 157 to 164 give examples of the isometric of various objects.Fig. 159 is the plan and elevation, and Fig. 100 the isometric, of acarpenters sawhorse. OBLIQUE PROJECTIONS In oblique projection, as in Lsometric, the…
