is usually de-noted by a small letter 771 with an index corresponding to its re-lated vanishing jioint. Thus, m* signifies the measure point forthe system of lines vanishing at v^^. 100. The vanishing point for ab in Fig. 26 has been found atv*^. The point n, in HPP, is the horizontal projection of…
