PERSPECTIVE DRAWING. nf-^ lias been found hy drawing an arc with n as center, and witha radius equal to the distance from n to SP^^, and dropping fromthe intersection of this arc with HPP a vertical line, nf-^ isfound at the intersection of this vertical line witli VH. 101. The perspective of ah…
