SHADOWS 9 28, Fig. 12 shows the construction for finding the shadowof a line so situated that part of the shadow faUs upon V and theremainder on H. To obtain the shadow in such a case, it must befound loliollij ovb eitlier one of the co-ordinatei)laiies. In Fig. 12,it has been found wholly on Y,…
