Kn.to 1)2. Problem XXV.To construct the shadowon a right cylinder of ahorizontal line. a. It will be the arcof a circle of the sameradius as that of the cyl-inder. b. The center of thecircle will be on the axisof the cylinder as far be-low the given line as thatline is in front of the axis. Given a… … FIG-47
