three for the corona, and three for the qiiarter-round and fillet. The archivolt is twenty-five in width composed ofa first band of seven, a cyma of two, a second band of nine, a bead ofone and five-tenths, a cyma of three, and a listel of two and five-tenths. The projection of the archivolt is… … Fig. 13. 80. The relation of Ionic colmnn taper to pilaster taper(Fig. 12) is as follows: The lower diameter of the Ionic column isforty-five, and its ujDper diameter thirty-nine, the differenceis six, which, divided into three parts, as in the Doric order, givesfor the lower width of the pilaster…
