H … Fig. 23. Frames. of the edges and all the lines drawn upon them. The tracingsillustrate the following; rule: Rule 24. In representing the regular frames, the anglesof the inner figure must he in straight lines passing from theangles of the outer figure to the center. These lines are alti-tudes or…
