35. inches. Make the distance 4 to C and •! to B both 3J inches anddraw C B. Draw the center line A F, on which line measure up2^ inches and obtain J, which nse as center with radius equal to a4, draw the section of the boiler D E F G. In its proper positiondraw the side view H I J K L M N. H I L M…
