A B as shownby similar letters and figures. Through these di\asions and at rightangles to A B draw lines which intersect with lines drawn at rightangles to C 4 from similar points in the curb section a f. Trace a linethrough points thus obtained; then E^ F^ / a wall be the half pattern forthe curb… … Fig. 177. the radius r s strike the semicircle shown. Above tliis .semicirclepunch the hole Y. Before the patterns can be obtained for the hip and jack bars, aquarter plan view must be constructed which -^-ill give the points ofintersections between the hip bar and curb, between the hip bar…
