59. TRANSMISSION BY ROPE to a shaft atright angles to the driving-shaft. The guide sheavesgive direction to the rope over the curve face of thedriven pulley, the rope slipping towards the centreof the driven pulley. 60. TRANSMISSION BY ROPE to a portable drill or swing saw. D, driving sheave. A,… … 61. HORIZONTAL ROPE TRANSMISSION, with tension•slide and weight.
