er frombacking up. Fig. 192 shows the style ofroof on which these shingles are employed,that is, on steep roofs. Note the con-struction of the ridge roll, A and B inFig. 192, which is first nailed in positionat a a etc., after which the shingles B areslipped under the lock c. Fig. 193 shows…
