ake c equal to f inch; d equal to 1 inch; e equal to finch; / equal to ^ inch; and with a radius equal to f inch, strike thecove shown, using a as center. Above the line A B, obtain the trueprofile for the return A B C F, and lay off this pattern at right angles toA F centrally between A F and the…
