pan with alapering handle passing through the back of the pan and solderedto the bottom. The first step is to draw the plan and elevationwhich is shown in Fig. 43. Let ABC be the side view of the pan.Directly below it, in its proper position, draw the bottom DEFG.From the point C in elevation draw…
