he floor above, whicheither rest directly on it or are notched over it according to circum-stances. These joists are marked P in the figure. They support theflooring R of the floor above the partition. The main members ofthe partition frame are filled in with ordinary studding, 2X4 inchesor 2X3… … Fig. 218. Building an Inclined Floor throughout, but should be so constructed as to be higher at the backend of the room thar it is at the front. The fall of such a floor fromback to front should be not more than f of an inch in 1 foot, and afall of ^ an inch in 1 foot is much better. If the floor…
