Fig. 112. Finding Bevel Where Upper Tangent InclinesMore Than Lower One. 334 STAIR-BUILDING 61 … Fig. 113. Finding Bevel Where Upper Tangent Inclines LessThan Lower One. are out of plumb. In the upper part of the figure, the wreath 6 is shown placed in its position upon the plane of the section, where its sides are seen to be plumb. It is evident, as shown in the relative posi- tionof the…
