GROUND FLOOR PLAN + H h H HOUSE AT ROYSTON, ENGLAND. John Belcher, A. R. A., Architect. Walls Built of Red Bricks with Overhanging Tiles and a Tiled Roof. The Entrance Porch is of Oak JRexirinted by permiCSion f7om Modern Cottage A>chitecture, John Lane Co., Publisher THE STEEL SQUARE 9 What is… … Fig. 13. Method of Finding Relative Height of Hip or Valley per Foot of Runto that of Common Rafter. the various pitches to the foot of rim. For the ^-pitch roof, the figuresas shown, from 12 on tongue to 12 on blade, are those to be used onthe steel square for the common rafter; and for f pitch,…
