Fig. 36. Example of a Splice … Fig. 37. Example of Plain Joint Fig. 38. Square Butt Joint one piece against the side of the other and naihng them firmly toeach other, after both have been trimmed square and true. Such ajoint is shown in Fig. 38. The two pieces are perpendicular to each 58
