Cyclopedia of architecture, carpentry, and building; a general reference work .. (1912)
American School (Lansing, Ill.) · Chicago, American school of correspondence · leaf 83
Fig. 46. Tenon-and-Tusk Joint with SpeciallyCut Tenon Piece 62 CARPENTRY 53 There are several ways of securing the tenon in place. Thesimplest is that shown in Fig. 47, where the pin B is passed throughthe tenon A and the mortised piece so as to hold the tenon securelyin place. Another scheme is to…
Architecture · Building
