steam distribution in balanced compound cylinders Figure 135 and between the two cylinders which they are arrangedto control. A separate set of guides and connectionsis required for each cylinder. COMPOUND LOCOMOTIVES 30: H J2JO M ? w • > 9 * o d Q O od tt … «04 LOCOMOTIVE ENGINEERING The two high-pressure cylinders being placed insidethe frames, the pistons are necessarily coupled to acrank axle. The low-pressure pistons are coupled tocrank-pins on the outside of the driving wheels. Thtcranks on the axle are set at 90 ° with each other, andat 1800…
