he body or shell of the valve, Thesearms have passages E E for the escape of the steamor other fluid from the well into the air when the valveis open. This well is deepened so as to allow the wingsX X of the valve proper to project down into it farenough to act as guides, and the flange G is for… … INJECTORS, STEAM GAUGES, ETC. 395 pound of the maximum pressure required, the valveopens slightly, and the steam escapes through theouter seat into the cylinder and thence into the air;the steam also enters through the inner seat into thewell, and thence through the passages in the arms tothe air.…
