of the mud ring exactlycentral and is placed at an angle so the jet or spray of oilwill strike just below or under the arch. Details of thearrangements of piping and brickwork of an oil-burninglocomotive are shown in Figs. 223a and 223c Ordinary commercial fire brick is used for side wallsand…
