Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 817
shown on opposite side of FG, where thecrank passes through the arc DJE during the exhaustperiod, with a positive exhaust lap of the size EF.When the exhaust edge of the valve is line and line,this arc becomes GFJ, or 1800, and when a negative lap 760 LOCOMOTIVE ENGINEERING (clearance) occurs, the… … Id/am 7 H FIG. 338. A CONVENIENT GAUGE FOR SETTING THE ECCENTRIC CRANK In Fig. 337 the eccentric and admission valve circlesare shown at different cut-offs where each set of linesand circles is governed by the same explanation as thoseof Fig. 336, where the admission points S, S,1 S2, S3,…
