such an angle that thedirection of the motion of the tool will coincide with tlie requiredtaper. Several methods are employed for this adjustment of thej-est. The tool is then fed to the work by means of the feedhandle attached to the compound rest. The taper attachment. Fig. 140, is in the form of… … Fia. 140. that calculations based on the length of the work are unnecessary.A slide moving with the guide is atfciched to the cross-feed of thecarriage. The cross-feed is loosened, and, while the carriage ismoved by the feeding mechanism, the tool is moved in or outaccording to the direction of the…
