eccentric held in thecliuck. Tlie diameter of the hole heing comparatively large, areamer is not generally used. The eccentric is now moved on thefaceplate a distance eijual to one-half the throw of the eccentric,Ijringing the outer surface concentric with the lathe axis, as shownhy the full lines,… … Boring. The horiiig of holes sometimes calls for a lengthand strength of tool that cannot he readily attained with the ordi-nary boring tool. A great deal of such boring is done withdouble-headed tools, ihese tools are held in bars and cut ateach end. An ordinary form of such a tool is shown iu…
