Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 173

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 173
UNIVERSAL MILLING MACHINE.Brown and Sharpe Mfg. Co. * MACHINE SHOP WORK. 127 THE SHAPER. For light -work tLe sliaper or shaping planer, Fig. 180, is ex-tensively used. It possesses the advantage of rapidity of action.In this machine, as in the plate planer, the tool moves while the … Fir. 180. work is at rest. A suitable mechanism causes the ram A to moveto and fro. When moving toward the left, the tool is cutting.As in the ordinary planer, the cutting speed is less than tiietetxrrn. 128 MACHINE SHOP VVOEK. The work is held on the table R, whicli may bo adjusted toany…
