Inventors at work, with chapters on discovery (1906)
Iles, George, 1852-1942 · New York, Doubleday, Page & company · leaf 133
Compound slide rest.C, shears; E, tool carriage; H, cross slide; K, crossslide handle; L, cross feed handle; P, tool post; T, tool;D, driver; W, work. … Blanchard Lathe.A, frame; B, carriage; C, gun stock; D, former; E, cutter-head; F, guide wheel; G, swinging frame; H, feed motion;K, shaft for revolving stock and former. TURRET LATHES 97 cutting wheel, and a friction wheel, equal in diameter. The cuttingwheel turns on a horizontal axle, and bears…Inventions · Inventors
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
