vertical direction. This knee carrieswhat i.s known as the saddle, the ujiper portion of which is also par-allel to the spindle. The move-ment of the saddle is towards andfrom the frame of the machine,and therefore parallel to thespindle. The saddle, in turn,carries the table to which thework is… … Fifr. ^09 three motions, at right angles to the spindle in the vertical plane,{)arallel to the spindle in the horizontal plane, and at right-anglesto the spindle in the horizontal ])lane, give to the milling machinewhat is known as its range. It allows any portion of the table tobe brought uwler…
