late by a spring. The arm D can be moved to anydesired position, relatively to the index plate, and there fastened.When a gear is to be cut, the arm D is moved so that the piuis opposite a row of holes the number of which is the same or amultiple of the niimber of teeth to be cut. Thus, suppose a…
