e formof a graduated arc, is appliedto the bevelj making what isknown as a protractor, shownin Fig. 13. Tiiis tool can beused to find the angular rela-tion in degrees or to produce that relation bj setting to tiiepioper point on the graduated arc. As the center of a circle is found at the… … result. As one edge of the rule bisects the angle of the square,it is evident that a line drawn by that edge passes through thecenter of any circular piece to which the square is applied.Centering the ends of i-ound bars or circular work of any kindis the principal use of this tool. Tiie center…
