Fig. 24 … MACHINE FOR PUNCHING OR SHEARING.Showing Motor and Gearing.The Long ami Allstatter Co. FORGING 19 out the scale and leaves a clean joint. As the pieces are driventogether they are more or less upset at the joint, making a sort ofa burr. This upset part should be worked down at a welding…
