Fig. 94. Fig. 9.-,. many forgings of the same general shape. The forging shown m FOUGING 53 Fig. 94 will be taken as an example. There are two general waysof making work of this character. One is to take stock of the propersize for the lever and weld on a chunk for the boss. Tiie other is totake… … Fig. 96.lever, or a short stub, to which the levei is welded. The work may bestarted for the first method by doubling over the end of the stock asillustrated in Fig. 95. This is welded up and rounded by the samegeneral method as afterwards described for the other boss. The
