Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 367
Fig. 109. FORGING 59 method employed. Two nicks are first made witli fullers as illus-trated at A and the stem (h-awn down, roughly, to size. This stemis tlien bent up at right angles and forged to a scpiare corner as illus- … CIT Fig. 110. trated at B, in the same general manner as the square corner of abracket is formed. Wien flattening out the blade in order to leavethe ridge shown at R, Fig, 112, the work sliould be held as shown at C, Fig. 113. Here the handle^ is held pointing dowTiward andagainst the side of the…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
