Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 94
he gears on the pulley and spindle, by means of theshaft having eccentric bearings upon which it turns ; at the sametime tlie cone pulley is fastened to the gear at its right. Thespindle then turns with the cone pulley. When the back gear isin use the spindle runs more slowly, with the belt on the… … 78 MACHINE SHOP WORK. 65 also bored out and tapered at the end for a center G. This cen-ter is called the lire center because it turns with the spindle. Thedead center II is in the tailstock, and hence does not turn. Atthe left the -spindle projects beyond the bearings, and carries asmall ooue…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
