Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 98
Fig. 39 the bolt to indicate where thecliamfer or the rounding of thepoint begins. Fig. 41 shows three views of a square head or nut with cham-fer corresponding to that on the hexagonal head in Fig. 30: andFig. 42 shows the square head or nut chamfered to correspond to … DIAGRAM FOR INSTALLING A 30-INCH VERTICAL TURRET MACHINE Warner and Swasey. ^ MECUAKICAL DRAWING 25 Fig. 37. Refemni^ first to Fig. 41 the arc on the side view whichshows the short diameter of the nut is drawn with a radiu.s A,equal to two and one-quarter times the diameter of the bolt onwhich the…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
