Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 257

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 257
f themold are to be handled by the crane. The sweeps are attached by means of the sweep arm d. Thedetail B shows one method of clamping sweep arm to spindle by usinga key. The arm is offset so that one face hangs in line with the centerof the spindle. Bolting the face side of the sweep to this… … Fig. 93. Rig for Loam Work. actually sweeping the surface is only about f inch. For very ac-curate work or when sweeps are to be much used, the edge is facedwith thin strap iron to prevent wear. We have seen that the walls of green and dry sand molds are sup-ported by sand packed into flasks and…

Mechanical engineering -- Dictionaries

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
