Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 364

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 364
Fig 12. these pulleys stretch a band, or belt made of some flexible nuite-rial. The pulleys are fastened to the shafts so that the pulley andits shaft turn totjether, and the belt is stretched over the pulleystiiht enouiih so that the friction between the belt and the surface … of the pulley is suflicient to make them travel with the samelinear velocity. A detailed study of the exact manner of findino;the proper locations of the pulleys and drawing the pulleys andbelts can be found in Mechanical Drawing Part V, so that we will 323 16 MECHANISM. now study only the general…

Mechanical engineering -- Dictionaries

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
