n to the shaft in either direction. The clutches are similarin principle to the one shown in Fig. 23. The left-hand clutch isshown partly cross-sectioned. The ])iece A is attached to a shipjierwhich when moved to the riglit throws in the right-hand clutch;when moved to the left throws in the… … Fig. 23. in either direction according as one or the other clutch is thrownin. When A is in the position shown neither clutch is in and theshaft is at rest. SCREWS. The Helix. Since all screws depend upon a curve known as
