Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)
American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 405
the tooth ]-,]M is made a littleless than the width of the S])ace KL, to allow for irregularity ofconstruction. The difference in the width of the two is cnlltMl ili.-back hf.sh. Although the circular pitch is a term which is frequentlyused in connection with gearing, there is another kind of… … MECHANISM. 55 tootli. The diametral pitch l>ears the same relation to the circu-lar pitch that the diameter of a circle bears to its circumference;that is, the diametral pitch is equal to the circular pitch dividedby TT. In speaking of the pitch of a gear, instead of using thediametral pitch,…
Mechanical engineering -- Dictionaries
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
