Beale, Oscar James, Brown & Sharpe Manufacturing Company (Providence, R.I.) · Providence, R.I. : Brown & Sharpe Mfg. Co. · leaf 50
the first tooth-thickness point on other sideof line of centers, C C, at v. The arc is continued ton, to show how constructed. This method of obtain-ing radius of double-curve tooth flanks applies to allgears having more than fifteen teeth. 4. The construction of tooth faces is similar to 15-tooth… … PINION, 12 TEETH,GEAR 24 TEETH, .4. P, P=4 N=12ancl24P= .7854t = .39278 = .2500D^ .5000St/ = .2893D+/ = .5393 DOUBLE CURVE GEARS IN MESH. 32 BROWN & SHARPE MFG. CO. Construction 5 ^j^^ radius of fillets at roots of teeth is equal to of Fig. 15 con- ^ -^ tinned. oiie-sixth the width of space at…
Gearing
