likely to dislodge some of theparticles and make it necessary to mend the mould. In order toavoid this, th(; diameter at a is made slightly greater than at I>, sothat the body of the gland is tax)ering, and the moment it is startedout the whole surface from « to J is clear of the sand and can… … Fis. 134. 72 PATTERN ]\rAKTNa 65 The allowance for dT;rift varies witli the i^attern, atid is oftengreater or less on different parts of the same pattern. For exaniijlc,the draft on the outside of the pattern of a pulley rim 24 inches indiameter and 0 inches face, should be ^ inch to the foot,…
