but it is usually found desirable only with simpleconstruction. It concentrates parts on the drawing, and probablysaves some time, besides showing the workman just how the partsgo together. Tlie only test which tlie student need to apply inthis, as in any method of detailing, is the test for… … MECHANICAL DRAWING. 65 The valve stem can be unscrewed either with a socketwrencli on the iiisitle or an ordinary fork wrench on the outside. The seat, after being screwed to position in the deck, isoften faced off, to true up any distortion caused by screwing in. The valve itself, of rubber, can…
