Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing (1908)

American School (Chicago, Ill.), Raymond, Howard Monroe · Chicago American Technical Society · leaf 261

An illustration from Cyclopedia of mechanical engineering; a general reference work. Editor-in-chief Howard Monroe Raymond. Assisted by a corps of mechanical engineers, technical experts, and designers of the highest professional standing, 1908, leaf 261
discovered only when the latteris turned in the lathe. Hence it seems reasonable and safe in this case to make thethickness of the drum depend simply upon the crushing caused bythe wrapping of the rope around it, and we shall take the coilnearest the free end of the rope, assuming that it carries… … 1- ill If 4!^ ii V I ^#+€ ^ 1 4 FI Fig. 15. 250 MACHINE DESIGN 53 of the groove. Assuming that ^ inch is tlie least thickness which can be safely allowed under the groove for casting purposes, lot us figure the crushing fibre stress to see if this is sutHciently strong. Disregarding the small…

Mechanical engineering

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
