sist the cantilever moment due to the toothload. The arms must, as in the case of spur gears, transmit the loadfrom the tooth to the shaft; in addition, the arms of a bevel gearare subjected to a side thrust due to the wedging action of thecones. Hence sidewise stiffness of the arms is more… … cated ; also that the trapezoid in most cases would be l)iit littledifferent from a true rectangle. Hence the error will be butslight if the average cross-section of the tooth be taken to repre-sent its strength, and the calculation made accordingly. 33 4
