Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 134

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 134
hows a plan of a coiler withthe top raised. The calender rolls arekept together by a spring, N^, on the endof Avhicli is a lever, L. When a wind-upoccurs on the calender rolls, the tensionupon the spring is removed by turning thelever.5top Motion. One of the recent improvements, which hasbeen… … Fig. 63. Plan of turn-table gearing.
